• Heavy Metal Online Analyzer (Chromium)
Heavy Metal Online Analyzer (Chromium)
  • Applicable Medium
    Water
  • Not applicable medium
    Gas
  • Product Introduction
    Nickel is a silver white, magnetic metal that is stable in air at room temperature and is an inactive element. Nickel is prone to react with nitric acid and has a slower reaction with dilute hydrochloric acid or sulfuric acid. Nickel exists in various minerals in nature and often combines with sulfur, arsenic, or antimony.

Working principle

The components to be tested in the water sample react with the digestion reagent to generate substances of different colors through digestion. The analyzer detects the color change of the generated substances and calculates the corresponding components to be tested within the range of Beer's law.

Product Features

1. Adopting GB/T7467-87 "Water Quality - Determination of Hexavalent Chromium - Diphenylcarbazide spectrophotometric method";

2. GB/T7466-87 "Water Quality - Determination of Total Chromium";

3. The intelligent fault self diagnosis function makes instrument management and maintenance very convenient;

4. Equipped with automatic range switching function, no manual setting required;

5. Equipped with reverse control function, the instrument can be remotely controlled through central control, increasing operational convenience;

6. Sampling methods such as timing, interval, and telemetry can be set;

7. After abnormal reset and power outage, the instrument will discharge residual reactants and automatically restore working status when powered on;

8. Suitable for process detection of surface water, groundwater, sewage, etc;

9. Having network functionality, remote control of data can be achieved through the network;

10. Sequential injection analysis method has a simple flow path, low reagent consumption, and high degree of automation;

11. Adopting multi-channel valves, it has strong anti-corrosion performance, long service life, and is safe and reliable.

Technical Parameter

model

YK-CR-3000

Method basis

Diphenylcarbazide spectrophotometric method

measuring range

0~10mg/L (expandable according to customer requirements)

Accuracy

Error ≤± 5%

Repetitive error

Error ≤± 5%

Measurement cycle

The minimum measurement cycle is 20 minutes

sampling period

Time interval (adjustable from 10 to 9999min) and hourly measurement mode

Correction mode

Manual and automatic modes

Communication output

RS232 or RS485 and analog (4~20) mA

Comparison of actual water samples

Error ≤± 10%

Size

Height 1430 x Width 500 x Depth 403 (mm)

application area

Online monitoring of industrial pollution source wastewater (chromium ore processing, metal surface treatment, leather tanning, electricity)

Electroplating, printing and dyeing, online monitoring of industrial process water, online monitoring of municipal sewage treatment plant imports and exports

Online monitoring of water quality for streams, lakes, reservoirs, groundwater, and surface water, etc
